产品详情

Based on the chameleon metallic series, this product uses a specially formulated transparent topcoat applied in two stages to achieve a powder coating with exceptional decorative effects and long-lasting durability. It is primarily used for outdoor applications, offering advantages such as excellent durability, formaldehyde-free emissions, and environmental friendliness.


360° Visual Effects:

Produces a strong 3D metallic effect from all angles

Customizable Color Shift Effects:

Visual effects can vary based on viewing angles

Enhanced Durability:

Superior to the standard chameleon metallic series, with customizable weather resistance grades.


Application Fields

A perfect substitute for conventional solvent-based metallic paints, it can be applied to various metal products with high appearance requirements.


Technical Specifications

Property

Test

Standard

Performance

Powder Properties

State in Container

HG/T 2006

Uniform color, free of foreign matter, loose

powder

Residue (125μm)

HG/T 2006

Fully passable

Mechanical

Chemical

& Durability

Properties

Adhesion

GB/T 9286

Grade 0

Impact

GB/T 1732

16mm indenter, depth 2.5±0.3mm; no cracking

or delamination

Cupping Test

GB/T 9753

5mm

Bending

GB/T 6742

≤ 3mm; no delamination

Condensation

ISO 6270-2

1000h, Grade 0

Salt Spray

GB/T 10125

Aluminum substrate: Acid salt spray 1000h, Unidirectional corrosion ≤ 4mm

Steel substrate: Neutral salt spray 500h, Unidirectional corrosion ≤ 2mm

Heat and Humidity

GB/T 1740

1000h, no blistering or peeling

Accelerated Aging

(B Lamp)

GB/T 23987

250h, gloss retention 50%

(customizable levels)
